高性能MCU

K8凯发·国际官方网站提供基于Arm? Cortex?内核的GD32高性能微控制器（MCU）

概述
产品线
产品组合
产品选择器

概述

GD32高性能MCU接纳领先工艺和内核架构，具备更高处置惩罚能力、更大存储容量、更富厚的片上资源，为开发者带来高端立异体验。高性能产品共包括6条产品线、22个产品系列，面向工业自动化、光伏储能、图形显示、数字电源、电机控制等多元化应用场景，为高级立异应用提供强盛的算力支持，推动嵌入式设计向智能化偏向生长。

产品线

GD32H7xx

接纳600MHz Arm^? Cortex^?-M7高性能内核，支持多种硬件加速，内置超大可配高速存储空间，实现兼具高性能和低延迟的实时控制。集成大宗通用外设资源、高精度模拟外设及多种音视频接口；支持多种清静机制，为通讯历程的数据清静提供包管。周全适用于数字信号处置惩罚、电机变频、电源、储能系统、音频视频、图形图像、机械学习和人工智能等应用。
GD32G5xx

接纳Arm^? Cortex^?-M33高性能内核，主频高达216MHz，全系列支持-40~105℃的宽温事情规模。依附精彩的处置惩罚性能、富厚多样的数字模拟接口资源以及强化的清静性能，可普遍适用于数字电源、充电桩、储能逆变、变频器、伺服电机、光通讯等多元化场景。
GD32F5xx

接纳Arm^? Cortex^?-M33高性能内核，主频抵达200MHz；内置多种主流外设、通讯接口以及音视频接口资源。最高支持7.5MB Flash，最高支持2MB程序RWW (Read-While-Write) OTA升级，知足重大工业系统关于代码升级备份的需求。同时推出Security Boot and Update软件平台，提供清静启动、清静升级、清静通讯及软件计划；支持系统级IEC61508 SIL2品级功效清静标准。
GD32F4xx

接纳Arm^? Cortex^?-M4内核，主频高达240MHz，具备快速的实时处置惩罚能力，可支持算法重漂后高的嵌入式应用。集成多种高性能的工业标准接口，为工控和物联网等装备互联需求提供高性价比解决计划。整合了强盛的运算效能和精彩的功耗效率，支持高级盘算、通讯网络、人机界面等多元化应用场景。
GD32E5xx

接纳Arm^? Cortex^?-M33内核，主频高达180MHz。同主频下的代码执行效率相比市场Cortex^?-M4产品提升了10%-20%。内置了全新的超高精度准时器，具备优异的防护抗滋扰能力，切合工业级高可靠性和温度标准。接纳磷七度集成化的立异设计，为实现普遍的工控和互联应用配备了更为富厚的标准外设资源。
GD32F2xx

接纳Arm^? Cortex^?-M3内核，主频抵达120MHz，配备了3MB Flash及256KB SRAM。增强了对视频图像、液晶显示、存储扩展以及高速信号收罗等应用的支持，并配备了增强的硬件加密�？橛肭寰布芄�。

探索我们的产品组合

Cortex?-M3

Cortex?-M4

Cortex?-M33

Cortex?-M7

高性能

GD32F207

120MHz, 3M/256K

GD32F205

120MHz, 3M/256K

GD32F470

240MHz, 3M/768K

GD32F427

200MHz, 3M/256K

GD32F425

200MHz, 3M/256K

GD32F450

200MHz, 3M/512K

GD32F407

168MHz, 3M/192K

GD32F405

168MHz, 3M/192K

GD32F403

168MHz, 3M/128K

GD32G553

216MHz，512K/128K

GD32F527

200MHz, 7680K/576K or 4608K/1088K

GD32E518

180MHz, 512K/128K

GD32E517

180MHz, 512K/128K

GD32E513

180MHz, 512K/128K

GD32E508

180MHz, 512K/128K

GD32E507

180MHz, 512K/128K

GD32E505

180MHz, 512K/128K

GD32E503

180MHz, 512K/128K

GD32H75E

600MHz, 3840K/1024K

GD32H759

600MHz, 3840K/1024K

GD32H757

600MHz, 3840K/1024K

GD32H737

600MHz, 3840K/1024K

产品选择器

隐藏筛选器

显示筛选器

重置

216条效果

导出

加载中

Part No.	Core Cortex?-M7 Cortex?-M4 Cortex?-M33 Cortex?-M3	Series GD32H75E GD32H759 GD32H757 GD32H737 GD32G553 GD32F527 GD32F470 GD32F450 GD32F427 GD32F425 GD32F407 GD32F405 GD32F403 GD32F207 GD32F205 GD32E518 GD32E517 GD32E513 GD32E508 GD32E507 GD32E505 GD32E503	Package WLCSP81 QFN48 LQFP80 LQFP64 LQFP48 LQFP176 LQFP144 LQFP128 LQFP100 BGA240 BGA176 BGA100	Max Speed (MHz) ≥ ≤	Flash (Bytes) 128K 256K 512K 1024K 2048K 3072K 3840K 4608K 7680K	SRAM (Bytes) 64K 80K 96K 128K 192K 256K 256K 512K 576K 768K 1024K 1088K	I/O up to 86 up to 82 up to 80 up to 66 up to 52 up to 51 up to 43 up to 39 up to 37 up to 140 up to 134 up to 121 up to 116 up to 114 up to 113 up to 112 up to 107	GPTM (32bit) ≥ ≤	GPTM (16bit) ≥ ≤	Advanced TM (16bit) ≥ ≤	HRTM ≥ ≤	Basic TM (64bit) ≥ ≤	Basic TM (32bit) ≥ ≤	Basic TM (16bit) ≥ ≤	LPTM (16bit) ≥ ≤	SysTick (24bit) ≥ ≤	WDG	RTC	USART+UART 3+2 3+0 4+4 4+2 8	I2C ≥ ≤	QSPI ≥ ≤	SPI ≥ ≤	I2S ≥ ≤	CAN 2.0B 2xFD 2 3xFD 3	USB 2.0 FS+HS FS OTG FS 0 (FS+HS) OTG 2x(FS+HS) OTG	Ethernet ≥ ≤	SDIO ≥ ≤	EtherCAT Slave Controller ≥ ≤	LCD-TFT ≥ ≤	Camera ≥ ≤	IPA ≥ ≤	SAI ≥ ≤	TMU ≥ ≤	EXMC ≥ ≤	14bit ADC Units (CHs) 0 1(20), 1(18) 1(16), 1(14) 1(14), 1(12) 2(22) 2(20)	12bit ADC Units (CHs) 1(4) 1(17) 1(15) 1(12) 2(16) 3(24) 3(21) 3(16) 3(10) 4(42) 4(39) 4(38) 4(26) 4(21) 4(20)	12bit DAC Units ≥ ≤	Comp ≥ ≤
GD32H75EYMJ6	Cortex?-M7	GD32H75E	BGA240	600	3840K	1024K	up to 116	4	10	2	0	2	2	0	0	1	2	1	8	4	1	6	4	3xFD	FS+HS	2	0	1	0	0	0	0	1	1	2(22)	1(15)	1	2
GD32H75EYMJ6B	Cortex?-M7	GD32H75E	BGA240	600	3840K	1024K	up to 113	3	9	2	0	2	2	0	0	1	2	1	8	4	1	6	4	3xFD	FS+HS	0	0	1	0	0	0	0	1	1	2(20)	1(15)	1	2
GD32H759IGT6	Cortex?-M7	GD32H759	LQFP176	600	1024K	1024K	up to 121	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	2x(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H759IIT6	Cortex?-M7	GD32H759	LQFP176	600	2048K	1024K	up to 121	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	2x(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H759IMT6	Cortex?-M7	GD32H759	LQFP176	600	3840K	1024K	up to 121	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	2x(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H759IGK6	Cortex?-M7	GD32H759	BGA176	600	1024K	1024K	up to 134	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	2x(FS+HS) OTG	2	2	0	1	0	1	3	1	1	1(20), 1(18)	1(17)	1	1
GD32H759IIK6	Cortex?-M7	GD32H759	BGA176	600	2048K	1024K	up to 134	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	2x(FS+HS) OTG	2	2	0	1	0	1	3	1	1	1(20), 1(18)	1(17)	1	1
GD32H759IMK6	Cortex?-M7	GD32H759	BGA176	600	3840K	1024K	up to 134	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	2x(FS+HS) OTG	2	2	0	1	0	1	3	1	1	1(20), 1(18)	1(17)	1	1
GD32H757VGT6	Cortex?-M7	GD32H757	LQFP100	600	1024K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H757VIT6	Cortex?-M7	GD32H757	LQFP100	600	2048K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H757VMT6	Cortex?-M7	GD32H757	LQFP100	600	3840K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H757VGJ6	Cortex?-M7	GD32H757	BGA100	600	1024K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H757VIJ6	Cortex?-M7	GD32H757	BGA100	600	2048K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H757VMJ6	Cortex?-M7	GD32H757	BGA100	600	3840K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H757ZGT6	Cortex?-M7	GD32H757	LQFP144	600	1024K	1024K	up to 113	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H757ZIT6	Cortex?-M7	GD32H757	LQFP144	600	2048K	1024K	up to 113	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H757ZMT6	Cortex?-M7	GD32H757	LQFP144	600	3840K	1024K	up to 113	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3xFD	(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H737VGT6	Cortex?-M7	GD32H737	LQFP100	600	1024K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	2	(FS+HS) OTG	1	2	0	0	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H737VIT6	Cortex?-M7	GD32H737	LQFP100	600	2048K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	3	(FS+HS) OTG	1	2	0	1	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H737VMT6	Cortex?-M7	GD32H737	LQFP100	600	3840K	1024K	up to 82	4	10	2	0	2	2	0	0	1	2	1	8	4	1	5	4	3	(FS+HS) OTG	1	2	0	1	0	1	2	1	1	1(14), 1(12)	1(4)	1	1
GD32H737ZGT6	Cortex?-M7	GD32H737	LQFP144	600	1024K	1024K	up to 113	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	2	(FS+HS) OTG	1	2	0	0	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H737ZIT6	Cortex?-M7	GD32H737	LQFP144	600	2048K	1024K	up to 113	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3	(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H737ZMT6	Cortex?-M7	GD32H737	LQFP144	600	3840K	1024K	up to 113	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3	(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H737IGT6	Cortex?-M7	GD32H737	LQFP176	600	1024K	1024K	up to 121	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	2	2x(FS+HS) OTG	1	2	0	0	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H737IIT6	Cortex?-M7	GD32H737	LQFP176	600	2048K	1024K	up to 121	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3	2x(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H737IMT6	Cortex?-M7	GD32H737	LQFP176	600	3840K	1024K	up to 121	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3	2x(FS+HS) OTG	1	2	0	1	0	1	3	1	1	1(16), 1(14)	1(12)	1	1
GD32H737IGK6	Cortex?-M7	GD32H737	BGA176	600	1024K	1024K	up to 134	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	2	2x(FS+HS) OTG	2	2	0	0	0	1	3	1	1	1(20), 1(18)	1(17)	1	1
GD32H737IIK6	Cortex?-M7	GD32H737	BGA176	600	2048K	1024K	up to 134	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3	2x(FS+HS) OTG	2	2	0	1	0	1	3	1	1	1(20), 1(18)	1(17)	1	1
GD32H737IMK6	Cortex?-M7	GD32H737	BGA176	600	3840K	1024K	up to 134	4	12	2	0	2	2	0	0	1	2	1	8	4	2	6	4	3	2x(FS+HS) OTG	2	2	0	1	0	1	3	1	1	1(20), 1(18)	1(17)	1	1
GD32G553QCT7	Cortex?-M33	GD32G553	LQFP128	216	256K	128K	up to 107	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(42)	8	8
GD32G553QET7	Cortex?-M33	GD32G553	LQFP128	216	512K	128K	up to 107	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(42)	8	8
GD32G553VCT7	Cortex?-M33	GD32G553	LQFP100	216	256K	128K	up to 86	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(42)	8	8
GD32G553VET7	Cortex?-M33	GD32G553	LQFP100	216	512K	128K	up to 86	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(42)	8	8
GD32G553MCY7TR	Cortex?-M33	GD32G553	WLCSP81	216	256K	128K	up to 66	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(39)	8	8
GD32G553MEY7TR	Cortex?-M33	GD32G553	WLCSP81	216	512K	128K	up to 66	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(39)	8	8
GD32G553MCT7	Cortex?-M33	GD32G553	LQFP80	216	256K	128K	up to 66	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(38)	8	8
GD32G553MET7	Cortex?-M33	GD32G553	LQFP80	216	512K	128K	up to 66	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(38)	8	8
GD32G553RCT7	Cortex?-M33	GD32G553	LQFP64	216	256K	128K	up to 52	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(26)	8	7
GD32G553RET7	Cortex?-M33	GD32G553	LQFP64	216	512K	128K	up to 52	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(26)	8	7
GD32G553CCT7	Cortex?-M33	GD32G553	LQFP48	216	256K	128K	up to 39	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(20)	8	7
GD32G553CET7	Cortex?-M33	GD32G553	LQFP48	216	512K	128K	up to 39	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(20)	8	7
GD32G553CCU7	Cortex?-M33	GD32G553	QFN48	216	256K	128K	up to 43	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(21)	8	7
GD32G553CEU7	Cortex?-M33	GD32G553	QFN48	216	512K	128K	up to 43	2	5	3	1	0	0	2	1	1	2	1	3+2	4	1	3	0	3xFD	0	0	0	0	0	0	0	0	1	1	0	4(21)	8	7
GD32F527IMT7	Cortex?-M33	GD32F527	LQFP176	200	4608K	1088K	up to 140	2	8	2	0	0	0	2	0	1	2	1	4+4	6	0	6	2	2xFD	(FS+HS) OTG	1	1	0	1	0	1	1	0	1	0	3(24)	2	0
GD32F527IST7	Cortex?-M33	GD32F527	LQFP176	200	7680K	576K	up to 140	2	8	2	0	0	0	2	0	1	2	1	4+4	6	0	6	2	2xFD	(FS+HS) OTG	1	1	0	1	0	1	1	0	1	0	3(24)	2	0
GD32F527IMK7	Cortex?-M33	GD32F527	BGA176	200	4608K	1088K	up to 140	2	8	2	0	0	0	2	0	1	2	1	4+4	6	0	6	2	2xFD	(FS+HS) OTG	1	1	0	1	0	1	1	0	1	0	3(24)	2	0
GD32F527ISK7	Cortex?-M33	GD32F527	BGA176	200	7680K	576K	up to 140	2	8	2	0	0	0	2	0	1	2	1	4+4	6	0	6	2	2xFD	(FS+HS) OTG	1	1	0	1	0	1	1	0	1	0	3(24)	2	0
GD32F527ZMT7	Cortex?-M33	GD32F527	LQFP144	200	4608K	1088K	up to 114	2	8	2	0	0	0	2	0	1	2	1	4+4	6	0	6	2	2xFD	(FS+HS) OTG	1	1	0	1	0	1	1	0	1	0	3(24)	2	0
GD32F527ZST7	Cortex?-M33	GD32F527	LQFP144	200	7680K	576K	up to 114	2	8	2	0	0	0	2	0	1	2	1	4+4	6	0	6	2	2xFD	(FS+HS) OTG	1	1	0	1	0	1	1	0	1	0	3(24)	2	0
GD32F527VMT7	Cortex?-M33	GD32F527	LQFP100	200	4608K	1088K	up to 82	2	8	2	0	0	0	2	0	1	2	1	4+4	3	0	5	2	2xFD	(FS+HS) OTG	1	1	0	1	0	1	1	0	1	0	3(16)	2	0
GD32F527VST7	Cortex?-M33	GD32F527	LQFP100	200	7680K	576K	up to 82	2	8	2	0	0	0	2	0	1	2	1	4+4	3	0	5	2	2xFD	(FS+HS) OTG	1	1	0	1	0	1	1	0	1	0	3(16)	2	0
GD32F527RMT7	Cortex?-M33	GD32F527	LQFP64	200	4608K	1088K	up to 51	2	8	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2xFD	(FS+HS) OTG	1	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F527RST7	Cortex?-M33	GD32F527	LQFP64	200	7680K	576K	up to 51	2	8	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2xFD	(FS+HS) OTG	1	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F470VET6	Cortex?-M4	GD32F470	LQFP100	240	512K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F470VGT6	Cortex?-M4	GD32F470	LQFP100	240	1024K	512K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F470VIT6	Cortex?-M4	GD32F470	LQFP100	240	2048K	768K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F470VKT6	Cortex?-M4	GD32F470	LQFP100	240	3072K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F470VGH6	Cortex?-M4	GD32F470	BGA100	240	1024K	512K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F470VIH6	Cortex?-M4	GD32F470	BGA100	240	2048K	768K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F470VKH6	Cortex?-M4	GD32F470	BGA100	240	3072K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F470ZET6	Cortex?-M4	GD32F470	LQFP144	240	512K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F470ZGT6	Cortex?-M4	GD32F470	LQFP144	240	1024K	512K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F470ZIT6	Cortex?-M4	GD32F470	LQFP144	240	2048K	768K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F470ZKT6	Cortex?-M4	GD32F470	LQFP144	240	3072K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F470IGH6	Cortex?-M4	GD32F470	BGA176	240	1024K	512K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F470IIH6	Cortex?-M4	GD32F470	BGA176	240	2048K	768K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F470IKH6	Cortex?-M4	GD32F470	BGA176	240	3072K	256K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F427RET6	Cortex?-M4	GD32F427	LQFP64	200	512K	256K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F427RGT6	Cortex?-M4	GD32F427	LQFP64	200	1024K	256K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F427RKT6	Cortex?-M4	GD32F427	LQFP64	200	3072K	256K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F427VET6	Cortex?-M4	GD32F427	LQFP100	200	512K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F427VGT6	Cortex?-M4	GD32F427	LQFP100	200	1024K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F427VKT6	Cortex?-M4	GD32F427	LQFP100	200	3072K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F427VEH6	Cortex?-M4	GD32F427	BGA100	200	512K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F427VGH6	Cortex?-M4	GD32F427	BGA100	200	1024K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F427VKH6	Cortex?-M4	GD32F427	BGA100	200	3072K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F427ZET6	Cortex?-M4	GD32F427	LQFP144	200	512K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F427ZGT6	Cortex?-M4	GD32F427	LQFP144	200	1024K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F427ZKT6	Cortex?-M4	GD32F427	LQFP144	200	3072K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F427IEH6	Cortex?-M4	GD32F427	BGA176	200	512K	256K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F427IGH6	Cortex?-M4	GD32F427	BGA176	200	1024K	256K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F427IKH6	Cortex?-M4	GD32F427	BGA176	200	3072K	256K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F425RET6	Cortex?-M4	GD32F425	LQFP64	200	512K	256K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F425RGT6	Cortex?-M4	GD32F425	LQFP64	200	1024K	256K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F425RKT6	Cortex?-M4	GD32F425	LQFP64	200	3072K	256K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F425VGT6	Cortex?-M4	GD32F425	LQFP100	200	1024K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F425VKT6	Cortex?-M4	GD32F425	LQFP100	200	3072K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F425VGH6	Cortex?-M4	GD32F425	BGA100	200	1024K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F425VKH6	Cortex?-M4	GD32F425	BGA100	200	3072K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F425ZGT6	Cortex?-M4	GD32F425	LQFP144	200	1024K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(24)	2	0
GD32F425ZKT6	Cortex?-M4	GD32F425	LQFP144	200	3072K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(24)	2	0
GD32F450VET6	Cortex?-M4	GD32F450	LQFP100	200	512K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F450VGT6	Cortex?-M4	GD32F450	LQFP100	200	1024K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F450VIT6	Cortex?-M4	GD32F450	LQFP100	200	2048K	512K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F450VKT6	Cortex?-M4	GD32F450	LQFP100	200	3072K	256K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	5	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(16)	2	0
GD32F450ZET6	Cortex?-M4	GD32F450	LQFP144	200	512K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F450ZGT6	Cortex?-M4	GD32F450	LQFP144	200	1024K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F450ZIT6	Cortex?-M4	GD32F450	LQFP144	200	2048K	512K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F450ZKT6	Cortex?-M4	GD32F450	LQFP144	200	3072K	256K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F450IGH6	Cortex?-M4	GD32F450	BGA176	200	1024K	256K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F450IIH6	Cortex?-M4	GD32F450	BGA176	200	2048K	512K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F450IKH6	Cortex?-M4	GD32F450	BGA176	200	3072K	256K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+4	3	0	6	2	2	(FS+HS) OTG	1	1	0	1	1	1	0	0	1	0	3(24)	2	0
GD32F407RET6	Cortex?-M4	GD32F407	LQFP64	168	512K	192K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F407RGT6	Cortex?-M4	GD32F407	LQFP64	168	1024K	192K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F407RKT6	Cortex?-M4	GD32F407	LQFP64	168	3072K	192K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F407VET6	Cortex?-M4	GD32F407	LQFP100	168	512K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F407VGT6	Cortex?-M4	GD32F407	LQFP100	168	1024K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F407VKT6	Cortex?-M4	GD32F407	LQFP100	168	3072K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F407VEH6	Cortex?-M4	GD32F407	BGA100	168	512K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F407VGH6	Cortex?-M4	GD32F407	BGA100	168	1024K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F407VKH6	Cortex?-M4	GD32F407	BGA100	168	3072K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(16)	2	0
GD32F407ZET6	Cortex?-M4	GD32F407	LQFP144	168	512K	192K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F407ZGT6	Cortex?-M4	GD32F407	LQFP144	168	1024K	192K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F407ZKT6	Cortex?-M4	GD32F407	LQFP144	168	3072K	192K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F407IEH6	Cortex?-M4	GD32F407	BGA176	168	512K	192K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F407IGH6	Cortex?-M4	GD32F407	BGA176	168	1024K	192K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F407IKH6	Cortex?-M4	GD32F407	BGA176	168	3072K	192K	up to 140	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	1	1	0	0	1	0	0	0	1	0	3(24)	2	0
GD32F405RET6	Cortex?-M4	GD32F405	LQFP64	168	512K	192K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F405RGT6	Cortex?-M4	GD32F405	LQFP64	168	1024K	192K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F405RKT6	Cortex?-M4	GD32F405	LQFP64	168	3072K	192K	up to 51	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F405VGT6	Cortex?-M4	GD32F405	LQFP100	168	1024K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F405VKT6	Cortex?-M4	GD32F405	LQFP100	168	3072K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F405VGH6	Cortex?-M4	GD32F405	BGA100	168	1024K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F405VKH6	Cortex?-M4	GD32F405	BGA100	168	3072K	192K	up to 82	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F405ZGT6	Cortex?-M4	GD32F405	LQFP144	168	1024K	192K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(24)	2	0
GD32F405ZKT6	Cortex?-M4	GD32F405	LQFP144	168	3072K	192K	up to 114	2	8	2	0	0	0	2	0	0	2	1	4+2	3	0	3	2	2	(FS+HS) OTG	0	1	0	0	1	0	0	0	0	0	3(24)	2	0
GD32F403RCT6	Cortex?-M4	GD32F403	LQFP64	168	256K	64K	up to 51	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F403RET6	Cortex?-M4	GD32F403	LQFP64	168	512K	96K	up to 51	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F403RGT6	Cortex?-M4	GD32F403	LQFP64	168	1024K	128K	up to 51	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F403RIT6	Cortex?-M4	GD32F403	LQFP64	168	2048K	128K	up to 51	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F403RKT6	Cortex?-M4	GD32F403	LQFP64	168	3072K	128K	up to 51	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F403VCT6	Cortex?-M4	GD32F403	LQFP100	168	256K	64K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VET6	Cortex?-M4	GD32F403	LQFP100	168	512K	96K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VGT6	Cortex?-M4	GD32F403	LQFP100	168	1024K	128K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VIT6	Cortex?-M4	GD32F403	LQFP100	168	2048K	128K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VKT6	Cortex?-M4	GD32F403	LQFP100	168	3072K	128K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VCH6	Cortex?-M4	GD32F403	BGA100	168	256K	64K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VEH6	Cortex?-M4	GD32F403	BGA100	168	512K	96K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VGH6	Cortex?-M4	GD32F403	BGA100	168	1024K	128K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VIH6	Cortex?-M4	GD32F403	BGA100	168	2048K	128K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403VKH6	Cortex?-M4	GD32F403	BGA100	168	3072K	128K	up to 80	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32F403ZCT6	Cortex?-M4	GD32F403	LQFP144	168	256K	64K	up to 112	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(21)	2	0
GD32F403ZET6	Cortex?-M4	GD32F403	LQFP144	168	512K	96K	up to 112	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(21)	2	0
GD32F403ZGT6	Cortex?-M4	GD32F403	LQFP144	168	1024K	128K	up to 112	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(21)	2	0
GD32F403ZIT6	Cortex?-M4	GD32F403	LQFP144	168	2048K	128K	up to 112	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(21)	2	0
GD32F403ZKT6	Cortex?-M4	GD32F403	LQFP144	168	3072K	128K	up to 112	0	8	2	0	0	0	2	0	0	2	1	3+2	2	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	1	0	3(21)	2	0
GD32F207VGT6	Cortex?-M3	GD32F207	LQFP100	120	1024K	256K	up to 82	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(16)	2	0
GD32F207VKT6	Cortex?-M3	GD32F207	LQFP100	120	3072K	256K	up to 82	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(16)	2	0
GD32F207ZCT6	Cortex?-M3	GD32F207	LQFP144	120	256K	128K	up to 114	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(24)	2	0
GD32F207ZET6	Cortex?-M3	GD32F207	LQFP144	120	512K	128K	up to 114	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(24)	2	0
GD32F207ZGT6	Cortex?-M3	GD32F207	LQFP144	120	1024K	256K	up to 114	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(24)	2	0
GD32F207ZKT6	Cortex?-M3	GD32F207	LQFP144	120	3072K	256K	up to 114	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(24)	2	0
GD32F207IET6	Cortex?-M3	GD32F207	LQFP176	120	512K	128K	up to 140	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(24)	2	0
GD32F207IGT6	Cortex?-M3	GD32F207	LQFP176	120	1024K	256K	up to 140	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(24)	2	0
GD32F207IKT6	Cortex?-M3	GD32F207	LQFP176	120	3072K	256K	up to 140	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(24)	2	0
GD32F207RCT6	Cortex?-M3	GD32F207	LQFP64	120	256K	128K	up to 51	0	10	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F207RET6	Cortex?-M3	GD32F207	LQFP64	120	512K	128K	up to 51	0	10	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F207RGT6	Cortex?-M3	GD32F207	LQFP64	120	1024K	256K	up to 51	0	10	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F207RKT6	Cortex?-M3	GD32F207	LQFP64	120	3072K	256K	up to 51	0	10	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS OTG	1	1	0	0	1	0	0	0	0	0	3(16)	2	0
GD32F207VCT6	Cortex?-M3	GD32F207	LQFP100	120	256K	128K	up to 82	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(16)	2	0
GD32F207VET6	Cortex?-M3	GD32F207	LQFP100	120	512K	128K	up to 82	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	1	1	0	1	1	0	0	0	1	0	3(16)	2	0
GD32F205RCT6	Cortex?-M3	GD32F205	LQFP64	120	256K	128K	up to 51	0	10	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F205RET6	Cortex?-M3	GD32F205	LQFP64	120	512K	128K	up to 51	0	10	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F205RGT6	Cortex?-M3	GD32F205	LQFP64	120	1024K	256K	up to 51	0	10	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F205RKT6	Cortex?-M3	GD32F205	LQFP64	120	3072K	256K	up to 51	0	10	2	0	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS OTG	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32F205VCT6	Cortex?-M3	GD32F205	LQFP100	120	256K	128K	up to 82	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	0	1	0	1	0	0	0	0	1	0	3(16)	2	0
GD32F205VET6	Cortex?-M3	GD32F205	LQFP100	120	512K	128K	up to 82	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	0	1	0	1	0	0	0	0	1	0	3(16)	2	0
GD32F205VGT6	Cortex?-M3	GD32F205	LQFP100	120	1024K	256K	up to 82	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	0	1	0	1	0	0	0	0	1	0	3(16)	2	0
GD32F205VKT6	Cortex?-M3	GD32F205	LQFP100	120	3072K	256K	up to 82	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	0	1	0	1	0	0	0	0	1	0	3(16)	2	0
GD32F205ZCT6	Cortex?-M3	GD32F205	LQFP144	120	256K	128K	up to 114	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	0	1	0	1	0	0	0	0	1	0	3(24)	2	0
GD32F205ZET6	Cortex?-M3	GD32F205	LQFP144	120	512K	128K	up to 114	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	0	1	0	1	0	0	0	0	1	0	3(24)	2	0
GD32F205ZGT6	Cortex?-M3	GD32F205	LQFP144	120	1024K	256K	up to 114	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	0	1	0	1	0	0	0	0	1	0	3(24)	2	0
GD32F205ZKT6	Cortex?-M3	GD32F205	LQFP144	120	3072K	256K	up to 114	0	10	2	0	0	0	2	0	1	2	1	4+4	3	0	3	2	2	FS OTG	0	1	0	1	0	0	0	0	1	0	3(24)	2	0
GD32E518CET6	Cortex?-M33	GD32E518	LQFP48	180	512K	128K	up to 37	1	12	2	1	0	0	2	0	1	2	1	3+0	3	0	3	2	3xFD	(FS+HS) OTG	0	0	0	0	0	0	0	1	0	0	3(10)	3	3
GD32E518RET6	Cortex?-M33	GD32E518	LQFP64	180	512K	128K	up to 51	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3xFD	(FS+HS) OTG	1	1	0	0	0	0	0	1	0	0	3(16)	3	3
GD32E518VET6	Cortex?-M33	GD32E518	LQFP100	180	512K	128K	up to 80	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3xFD	(FS+HS) OTG	1	1	0	0	0	0	0	1	1	0	3(16)	3	3
GD32E518ZET6	Cortex?-M33	GD32E518	LQFP144	180	512K	128K	up to 112	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3xFD	(FS+HS) OTG	1	1	0	0	0	0	0	1	1	0	3(21)	3	3
GD32E517RCT6	Cortex?-M33	GD32E517	LQFP64	180	256K	96K	up to 51	1	6	1	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	1	0	0	0	0	0	1	0	0	3(16)	3	3
GD32E517RET6	Cortex?-M33	GD32E517	LQFP64	180	512K	128K	up to 51	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	1	0	0	0	0	0	1	0	0	3(16)	3	3
GD32E517VCT6	Cortex?-M33	GD32E517	LQFP100	180	256K	96K	up to 80	1	6	1	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	1	0	0	0	0	0	1	1	0	3(16)	3	3
GD32E517VET6	Cortex?-M33	GD32E517	LQFP100	180	512K	128K	up to 80	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	1	0	0	0	0	0	1	1	0	3(16)	3	3
GD32E517ZCT6	Cortex?-M33	GD32E517	LQFP144	180	256K	96K	up to 112	1	6	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	1	0	0	0	0	0	1	1	0	3(21)	3	3
GD32E517ZET6	Cortex?-M33	GD32E517	LQFP144	180	512K	128K	up to 112	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	1	0	0	0	0	0	1	1	0	3(21)	3	3
GD32E513CCO6	Cortex?-M33	GD32E513	QFN48	180	256K	96K	up to 37	1	6	1	1	0	0	2	0	1	2	1	3+0	3	0	3	2	2	FS	0	0	0	0	0	0	0	1	0	0	3(10)	3	3
GD32E513CCT6	Cortex?-M33	GD32E513	LQFP48	180	256K	96K	up to 37	1	6	1	1	0	0	2	0	1	2	1	3+0	3	0	3	2	2	FS	0	0	0	0	0	0	0	1	0	0	3(10)	3	3
GD32E513CET6	Cortex?-M33	GD32E513	LQFP48	180	512K	128K	up to 37	1	12	1	1	0	0	2	0	1	2	1	3+0	3	0	3	2	2	FS	0	0	0	0	0	0	0	1	0	0	3(10)	3	3
GD32E513RCT6	Cortex?-M33	GD32E513	LQFP64	180	256K	96K	up to 51	1	6	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	1	0	0	3(16)	3	3
GD32E513RET6	Cortex?-M33	GD32E513	LQFP64	180	512K	128K	up to 51	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	1	0	0	3(16)	3	3
GD32E513VCT6	Cortex?-M33	GD32E513	LQFP100	180	256K	96K	up to 80	1	6	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	1	1	0	3(16)	3	3
GD32E513VET6	Cortex?-M33	GD32E513	LQFP100	180	512K	128K	up to 80	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	1	1	0	3(16)	3	3
GD32E513ZCT6	Cortex?-M33	GD32E513	LQFP144	180	256K	96K	up to 112	1	6	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	1	1	0	3(21)	3	3
GD32E513ZET6	Cortex?-M33	GD32E513	LQFP144	180	512K	128K	up to 112	1	12	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	1	1	0	3(21)	3	3
GD32E508RET6	Cortex?-M33	GD32E508	LQFP64	180	512K	128K	up to 51	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3xFD	(FS+HS) OTG	1	0	0	0	0	0	0	1	0	0	2(16)	2	3
GD32E508VET6	Cortex?-M33	GD32E508	LQFP100	180	512K	128K	up to 80	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3xFD	(FS+HS) OTG	1	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E508ZET6	Cortex?-M33	GD32E508	LQFP144	180	512K	128K	up to 112	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3xFD	(FS+HS) OTG	1	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E507RCT6	Cortex?-M33	GD32E507	LQFP64	180	256K	96K	up to 51	1	3	1	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	0	0	0	0	0	0	1	0	0	2(16)	2	3
GD32E507RET6	Cortex?-M33	GD32E507	LQFP64	180	512K	128K	up to 51	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	0	0	0	0	0	0	1	0	0	2(16)	2	3
GD32E507VCT6	Cortex?-M33	GD32E507	LQFP100	180	256K	96K	up to 80	1	3	1	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E507VET6	Cortex?-M33	GD32E507	LQFP100	180	512K	128K	up to 80	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E507ZCT6	Cortex?-M33	GD32E507	LQFP144	180	256K	96K	up to 112	1	3	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E507ZET6	Cortex?-M33	GD32E507	LQFP144	180	512K	128K	up to 112	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	1	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E505RBT6	Cortex?-M33	GD32E505	LQFP64	180	128K	80K	up to 51	1	3	1	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	0	0	0	0	0	0	0	1	0	0	2(16)	2	3
GD32E505RCT6	Cortex?-M33	GD32E505	LQFP64	180	256K	96K	up to 51	1	3	1	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	0	0	0	0	0	0	0	1	0	0	2(16)	2	3
GD32E505RET6	Cortex?-M33	GD32E505	LQFP64	180	512K	128K	up to 51	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	0	0	0	0	0	0	0	1	0	0	2(16)	2	3
GD32E505VCT6	Cortex?-M33	GD32E505	LQFP100	180	256K	96K	up to 80	1	3	1	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	0	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E505VET6	Cortex?-M33	GD32E505	LQFP100	180	512K	128K	up to 80	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	0	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E505ZCT6	Cortex?-M33	GD32E505	LQFP144	180	256K	96K	up to 112	1	3	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	0	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E505ZET6	Cortex?-M33	GD32E505	LQFP144	180	512K	128K	up to 112	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	3	(FS+HS) OTG	0	0	0	0	0	0	0	1	1	0	2(16)	2	3
GD32E503CCT6	Cortex?-M33	GD32E503	LQFP48	180	256K	96K	up to 37	1	3	1	1	0	0	2	0	1	2	1	3+0	3	0	3	2	2	FS	0	0	0	0	0	0	0	0	0	0	3(10)	2	0
GD32E503CET6	Cortex?-M33	GD32E503	LQFP48	180	512K	128K	up to 37	1	9	1	1	0	0	2	0	1	2	1	3+0	3	0	3	2	2	FS	0	0	0	0	0	0	0	0	0	0	3(10)	2	0
GD32E503RCT6	Cortex?-M33	GD32E503	LQFP64	180	256K	96K	up to 51	1	3	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32E503RET6	Cortex?-M33	GD32E503	LQFP64	180	512K	128K	up to 51	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	0	0	0	3(16)	2	0
GD32E503VCT6	Cortex?-M33	GD32E503	LQFP100	180	256K	96K	up to 80	1	3	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32E503VET6	Cortex?-M33	GD32E503	LQFP100	180	512K	128K	up to 80	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	0	1	0	3(16)	2	0
GD32E503ZCT6	Cortex?-M33	GD32E503	LQFP144	180	256K	96K	up to 112	1	3	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	0	1	0	3(21)	2	0
GD32E503ZET6	Cortex?-M33	GD32E503	LQFP144	180	512K	128K	up to 112	1	9	2	1	0	0	2	0	1	2	1	4+2	3	0	3	2	2	FS	0	1	0	0	0	0	0	0	1	0	3(21)	2	0
