| Part NO. | Status | Vin_min (V) | Vin_max (V) | Output Current (A)Max | Vout_min (V) | Vout_max(V) | Ground Current (μA) | PSRR(db) | Dropout Voltage (mV) | Operating Temperature Range(°C) | Package |
|---|---|---|---|---|---|---|---|---|---|---|---|
| GD30LD3300FUTR | MP | 1.1 | 6.5 | 3 | 0.5 | 5.2 | 3000 | 42@10kHz | 180 @ 3A with Bias | -40 to +125 | QFN20 |
| GD30LD3301FUTR | MP | 1.1 | 6.5 | 3 | 0.8 | 5.2 | 3000 | 42@10kHz | 180 @ 3A with Bias | -40 to +125 | QFN20 |
| GD30LD3137WETR | MP | 1.1 | 6.5 | 1.2 | 0.8 | 5.5 | 3000 | 40@500kHz | 70 @ 1.2A with Bias | -40 to +125 | DFN8 |
| GD30LD1003FUTY-I | MP | 1.1 | 6.5 | 2 | 0.8 | 5.2 | 3000 | 39@500KHz | 125 @ 2A with Bias | -40 to +125 | QFN20 |
| GD30LD1030MUTR-I | MP | 1.1 | 6.5 | 3 | 0.5 | 5.2 | 3000 | 39@500KHz | 180 @ 3A with Bias | -40 to +125 | QFN12 |
| GD30LD1000WGTR-I | MP | 1.4 | 6.5 | 2 | 0.5 | 5.2 | 3000 | 39@500KHz | 300 @ 2A | -40 to +125 | SOP8 |
| GD30LD1000NBTR-I | MP | 1.4 | 6.5 | 2 | 0.5 | 5.2 | 3000 | 39@500KHz | 300 @ 2A | -40 to +125 | TO263 |
| GD30LD1001LUTR | MP | 1.4 | 6.5 | 2 | 0.5 | 5.2 | 3000 | 39@500KHz | 180 @ 2A | -40 to +125 | QFN16 |
| GD30LD1002WETR-I | MP | 1.4 | 6.5 | 1.2 | 0.5 | 5.2 | 3000 | 39@500KHz | 200 @ 2A | -40 to +125 | DFN8 |
| GD30LD1031NBTR-I | MP | 1.4 | 6.5 | 3 | 0.5 | 5.2 | 3000 | - | 300 @ 2A | -40 to +125 | TO263 |
| GD30LD2000X | MP | 1.9 | 5.5 | 0.3 | 0.8 | 3.6 | 0.8 | 50@1KHz | 180 @ 0.2A | -40 to +125 | SOT235/SOT233/DFN 1x1 |
| GD30LD2001X | MP | 2.5 | 5.5 | 0.3 | 1.2 | 5 | 0.3 | 60@1KHz | 270 @ 0.2A | -40 to +85 | SOT235/SOT233/DFN 1x1 |
| GD30LD2010X | MP | 1.5 | 7 | 0.5 | 0.8 | 5 | 40 | 87@1KHz | 520 @ 0.2A | -40 to +125 | SOT235/DFN 1x1 |
| GD30LD2011X | MP | 1.8 | 7 | 0.5 | 1.2 | 5 | 40 | 80@1KHz | 270 @ 0.2A | -40 to +85 | SOT233/DFN 1x1 |
| GD30LD2100X | MP | 2.3 | 10 | 0.4 | 1.5 | 5 | 2.1 | 76@1KHz | 300 @ 0.2A | -40 to +85 | SOT235/SOT233/DFN 1x1/SOT893 |
| GD30LD2400X | MP | 2.5 | 45 | 0.35 | 1.8 | 5 | 2.5 | 60@1KHz | 690 @ 0.2A | -40 to +125 | SOT235/SOT233/DFN 1x1/SOT893 |
| GD30LD2401X | MP | 2.5 | 36 | 0.25 | 1.8 | 5 | 2.5 | 60@1KHz | 690 @ 0.2A | -40 to +125 | SOT235/SOT233/DFN 1x1/SOT893 |
| GD30LD2402X | MP | 3 | 30 | 0.2 | 3 | 5 | 1.5 | 40@1KHz | 1000/1200 @ 0.2A | -40 to +125 | SOT235/SOT233/SOT893 |
| GD30LD2404X | MP | 3 | 30 | 0.2 | 3 | 5 | 1.5 | 40@1KHz | 1000 @ 0.2A | -40 to +125 | SOT235/SOT233/SOT893 |
| GD30LD2406X | MP | 3 | 40 | 0.2 | 3 | 5 | 2.5 | 70@1KHz | 1600 @ 0.2A | -40 to +125 | SOT235/SOT233/SOT893 |
