| Part NO. | Control Topology | Control Interface | Series Cells | Vin_min (V) | Vin_max (V) | Charging Current (A) | Charging Efficiency (%) | CV Charge Voltage (V) | Quiescent Current (μA) | Temperature Operating Range(°C) | Package |
|---|---|---|---|---|---|---|---|---|---|---|---|
| GD30BC2501LRTR | Buck | I2C | 4,6 | 18 | 32 | 5 | 95 | 4.1/4.2/4.3/4.35 | - | -40 to +85 | QFN16 |
| GD30BC2502LRTR | Buck | I2C | 2,3,5 | 9 | 32 | 5 | 95 | 4.1/4.2/4.3/4.35 | - | -40 to +85 | QFN16 |
| GD30BC2416FUTR | Buck(Charging)- Boost(Discharging) | I2C | 1 | 4.4 | 5.5 | 1.5 | 97 | 4.1/4.2/4.3/4.35/4.4 | - | -20 to +85 | QFN20 |
| GD30WS8663DYTR | Linear-Mode | I2C | 1 | - | 36 | 0.008~0.456 | - | 3.6~4.545(15mV/step) | - | -40 to +125 | WLCSP9 |
| GD30BC1502x | Linear-Mode | - | 1 | - | 36 | 0.6 | - | 4.2/4.35 | - | -40 to +125 | SOT235 |
| GD30BC1500x | Linear-Mode | - | 1 | - | 36 | 0.8 | - | 4.2/4.35 | - | -40 to +125 | SOT235 |
| GD30BC1501x | Linear-Mode | EN | 1 | - | 36 | 1 | - | 4.2/4.35 | - | -40 to +125 | ESOP8/DFN2*2/DFN3*3 |
| GD30BC1503x | Linear-Mode | EN | 1 | - | 36 | 1 | - | 4.2/4.35 | - | -40 to +125 | ESOP8/DFN2*2/DFN3*3 |
